Full Stack App

Architecture

• Visitor / SPA: Anyone clicking a short link (hot path), plus the React admin SPA for creating and managing links.
• CloudFront: One distribution, two behaviors: static SPA from S3, everything else (short codes + /api/*) to API Gateway. Custom short domains attach here as aliases with ACM certs.
• SPA Assets: Private bucket with the built React admin app, served via Origin Access Control.
• API Gateway (HTTP API): GET /{code} routes to the redirect function with no authorizer (redirects must be anonymous). /links and /domains routes use the Cognito JWT authorizer.
• Cognito User Pool: Accounts for people who create and manage links. Following a link never requires auth.
• Redirect Fn (hot path): One GetItem, one 301. Fires a link.clicked message to SQS without awaiting it — no synchronous writes on the hot path. 128 MB, provisioned concurrency in prod.
• Links API Fn: CRUD for links and custom domains: validates URLs, generates or reserves codes (conditional Put), lists a user's links via the owner GSI.
• links table: On-demand. PK = short code for O(1) redirect lookups; expires_at is the DynamoDB TTL attribute so dead links vanish for free. GSI1 (owner_id, created_at) lists "my links". Daily click rollups live alongside.
• click-events queue: Buffers link.clicked events so the redirect path never waits on analytics. DLQ after 3 receives.
• Analytics Fn: Consumes clicks in batches of up to 100, aggregates per code per day, then a handful of UpdateItem ADDs: total click_count on the link plus a clicks_daily rollup row.

Event flow

• Redirect Fn: Fires one link.clicked per successful 301; send is fire-and-forget so the hot path never waits.
• click-events: Standard SQS queue; at-least-once, so the consumer aggregates idempotently. DLQ after 3 receives.
• Analytics Fn: Batch size 100 / 30s window. Aggregates per (code, UTC day) then UpdateItem ADDs the rollups in the links table.
• link.clicked: Emitted by the Redirect Fn on every successful redirect, without awaiting the send. No PII: IP is salted-hashed for rough uniqueness only.

Sequence

Participants: Browser, CloudFront, API Gateway, Redirect Fn, links table, click-events (SQS), Analytics Fn, Destination site

• Browser→CloudFrontGET https://zst.li/x7Kp2q
• CloudFront→API Gatewayforward /{code} (cache miss)
• API Gateway→Redirect Fninvoke (no authorizer on this route)
• Redirect Fn→links tableGetItem pk = 'x7Kp2q'The only synchronous data access on the hot path.
• links table→Redirect Fn{ long_url, expires_at, ... }
• Redirect Fn→click-events (SQS)SendMessage link.clicked (fire-and-forget)Not awaited; a send failure is logged, never blocks the redirect.
• Redirect Fn→API Gateway301 Location: long_url
• API Gateway→CloudFront301
• CloudFront→Browser301 (Cache-Control: no-store)
• Browser→Destination siteGET long_urlBrowser follows the Location header.
• Redirect Fn→API Gateway404 unknown code / 410 expired410 when the item exists but expires_at has passed (TTL deletion lags a little).
• API Gateway→CloudFront404 / 410
• CloudFront→Browser404 / 410 error page
• click-events (SQS)→Analytics Fnbatch of link.clicked (≤100)
• Analytics Fn→links tableUpdateItem ADD click_count; ADD clicks_daily[code, day]Aggregated per code per UTC day before writing — a 100-click batch is a handful of writes.
• links table→Analytics FnOK (failed batch items retried, then DLQ)

API contract

• GET/{code}Resolve a short link (hot path, no auth)
• POST/linksCreate a short link (auth)
• GET/linksList my links (auth)
• DELETE/links/{code}Delete a link (auth)
• GET/links/{code}Get one of my links (auth)
• GET/links/{code}/statsClick analytics for a link (auth)
• POST/domainsRegister a custom short domain (auth)
• GET/domainsList my custom domains (auth)

Database

About this design

What this is

A serverless URL shortener with the shape of a real product: a hot-path redirect Lambda in front of DynamoDB, TTL-based link expiry, asynchronous click analytics over SQS, a Cognito-protected management API, and optional custom short domains. A React admin SPA (served from S3 via CloudFront) is where links get created; following a link needs no account and touches almost nothing.

The design optimises exactly one thing: GET /{code} must be one read and one 301. Everything else — counting, rollups, ownership, expiry — is arranged so it never adds latency to that path.

How it works

Redirect hot path — CloudFront forwards /{code} to API Gateway (no authorizer), the Redirect Fn does a single GetItem on the links table (PK = code), sends a link.clicked message to SQS without awaiting the result, and returns 301 Location: long_url. Missing codes return 404; TTL-expired ones 410.

Expiry — expires_at is the DynamoDB TTL attribute. Expired links are deleted by DynamoDB itself; the Redirect Fn also checks the timestamp so links that expired seconds ago (TTL deletion lags) still return 410.

Analytics — the Analytics Fn consumes SQS batches (up to 100 clicks), aggregates per code per UTC day, and issues a few UpdateItem ADDs: total clickcount on the link plus a clicksdaily rollup row with referrer/country maps. Stats queries never scan raw events. A DLQ catches poison messages.

Management — /links and /domains sit behind a Cognito JWT authorizer. Creating a link is a conditional Put (attributenotexists(code)), so custom-code collisions surface as 409 instead of silent overwrites. GSI1 (ownerid, createdat) lists "my links" newest first.

Custom domains — a domains row tracks DNS verification and the ACM cert; verified domains attach to CloudFront as aliases, and codes carry a domain attribute.

The sequence diagram traces the redirect hot path end to end, including the async aggregation leg; the event flow shows the link.clicked contract.

How to extend

Shave the hot path further: move redirects to CloudFront Functions/Lambda@Edge with DynamoDB global tables, or add short-TTL CloudFront caching per code.

Richer analytics: tee link.clicked to Kinesis Firehose → S3 and query raw events with Athena; add bot filtering before counting.

Product features: QR codes per link, password-protected links, per-owner rate limits (WAF), link preview/unfurl metadata.

Abuse controls: check long_url against Safe Browsing on create, and add a disabled flag the Redirect Fn honours.
